The two blocks in an Atwood machine have...

The two blocks in an Atwood machine have masses 2.0 kg and 3.0 kg. Find the work done by gravity during the fourth second after the system is released from rest.

Text Solution

Verified by Experts

Given, `m_1=3kg`
`m_2=2kg, t=during 4th sec `
From the freebody diagram,…i
`T-3g+3a=0`……….i
`T-2g-2a=0`……….ii
eqaution i and ii we get
`3g-3=2g+2a`
`rarr a=g/5 m/sec^2


Distance travelled in 4th sec is given by
`S4th=a/2(2n-1)`
`((g/5))/2(2xx4-1)`
`(7g)/10=(7xx9.8)/0 m
Net mass m `=m_1-m_2=3-2=1kg` So, decrease in P.E. =mgh `
`1xx9.8xx(7/10)xx9.8=67.2=67J`
